Iveco Daily 4x4
55 S 18 W Compact cab
Wheel base 3400 mm (134")
Engine performance 130 kW / 176 hp, Euro 4
Cruise control
Manual 6-speed transmission
Transfer case with off-road gear reduction
Permanent all wheel drive with engageable central differential lock
Differential lock in front and rear axle
Parabolic leaf springs
Rear drum brakes
Front disk brakes
Tires 255/100 R 16 tubeless
2 chamber fuel tanks, capacity 285 liters (75 US gallons)
Heated fuel prefilter with water separator
Aluminum roof rack with platform for spare wheel
2 working lights sideways
Light guards front and rear
Radiator and oil pan guard
Suspended driver seat, heated
2-seater bench
Integrated air conditioning
Auxiliary heating
Back eye camera
Alarm system and power locks with remote control
Immobilizer
Body
Outer dimensions of the cabin
Length 3700 mm (146"), width 2120 mm (83.5"), height 2105 mm (82.9")
Inner dimensions of the cabin
Length 3580 mm (141"), width 2000 mm (79"), height 1950 mm (77")
Frame assembly
3-point kinematic attachment with main and flex mounts
for stress-free body coupling to the torsion elastic chassis frame
Body unit construction
Self supporting UNICAT sandwich plate panels of fiberglass composite
Panel connections made by adhesive bond to custom extrusions
eliminates metallic heat conduction paths
Matched thermal coefficients of expansion prevent distortion with changes in temperature
Wall thickness 60 mm (2.36") with polyurethane foam insulation, 3 mm (0.12") fiberglass reinforced polyester outer surface, 2 mm (0.08") fiberglass reinforced polyester inner surface,
insulation rating 0.44 W/m2 K (0.078 Btu/ft2 hr °F)
Bottom panel with integrated welded steel frame and surfaces of fiberglass reinforced polyester
Slope at rear to improve slope angle
Slanted front of body for better aerodynamics and appearance
Entrance door and storage compartment doors
Entrance door and storage compartment doors
constructed of fiberglass composite panels and frames
Thickness of doors 60 mm (2.36")
Double sealed doors with heavy duty locks with seal compression
Stainless steel hinges throughout
Additional retractable bolts at top and bottom of entrance door
Safety cylinder locks all keyed alike
Windows
Burglarproof, scratchproof top-hinged windows with fiberglass frames
Double insulated thermal window glass
Double seals with heavy duty lock
Stainless steel hinges throughout
Stainless steel lifting and locking device
Aluminum-frame black-out and mosquito blinds
Fixed windows in the front
Skylights
Seitz lift-tilt-roof-hatch above kitchen and bathroom
Interior layout
Seating area
Seating area for 2-4 persons on pedestal in the front of the cabin
Swiveling, lowerable table
Seating unit converts to additional bed (size: 1100 x 2000 mm)
Beds
Bunk beds with suspension, ventilation, heating and comfortable mattress in the rear
Size: 800 x 2000 mm (31" x 79")
Sanitary room
Combined shower and toilet room with door to isolate from living area
Column with swiveling wash basin
Wall cupboard with mirror
Kitchen
Countertop with integrated stainless steel sink
LPG 3-flame stove with LPG oven
85 liter (22 US gallon) fridge with freezer rated 3 stars
Kitchen cabinet with drawers on ball bearings
Shock-proof separation for tableware, cookware and kitchen appliances
Overhead cupboards above kitchen
Storage
Large wardrobe with drawers and clothes rail
Storage boxes in seating area
Outside storage compartment under the bed
Aluminum exterior storage boxes
Workmanship
All furniture is built to the highest cabinetmaking standard,
made of wood core plywood using heavy duty locks and hinges
White surfaces and teak edges
Layout
Teak floor
Walls and ceiling are painted with multiple coats
Upholstery made of ALCANTARA
Technical equipment
Electrical equipment
Control panel for power management and monitoring of liquid levels
Battery main switch, fault current breaker, safety cut out
DC power supplied by AGM battery bank
Battery capacity: 12 V – 420 Ah
Charged by vehicle's alternator with charge distributor
Inverter/charger 230 V AC, continuous output 1.3 kW, peak output 3 kW, charge rate 70 A
Power plugs for 12 V DC and 230 V AC
Solar power system 12 V – 520 W
Music system
Stereo music system with CD player and MP3 / iPod input
Speakers in the seating area
Lighting
LED ceiling lights above the table, kitchen, corridor and shower
Reading lights in bed and seating area
Lights for outside storage compartment
Water supply
360 liter (95 US gallon) freeze-proof drinking water tanks
20 liter (5.3 US gallon) hot water heat-exchanger and auxiliary electric heater
All plumbing is insulated to prevent freezing
Waste water tank, capacity 80 liters (21 US gallons), freeze-proof
Outside shower
Water filtration system
LPG supply
20 liter LPG tank
Toilet
Dometic porcelain toilet with water flushing
Removable rollable sewage cassette tank, capacity 19 liters (5 US gallons)
Heating system
Diesel powered warm water central heating,
with engine preheating and drivers cab preheating system
Connection of heating system with the engine cooling system
High radiant heat share due to radiators in living area and sanitary room
Towel dryer type radiator, mounted in the shower
Additional heater in bed area
Others
Mounting for 6 sand ladders
Lashing rails on roof top
Lashing and tie-down rings for rescue or shipping
General information
GVWR
5,900 kg (13,000 lbs)
Overall dimensions
Length 6163 mm (243"), width 2120 mm (83"), height 3230 mm (127").
